KIE :: Public API 6.4.0.Final

KIE :: Public API 6.4.0.Final API

KIE provides a knowledge-centric API, where rules and processes are first class citizens.

See: Description

KIE Base API
Package Description
org.kie.api
Base KIE API classes.
Builder API
Package Description
org.kie.api.builder
org.kie.api.builder.model
Definition API
Package Description
org.kie.api.definition
All classes to create definitions, as built by the KieBuilder from artifact resources, can be found here.
org.kie.api.definition.process
The classes that make up a Process definition.
org.kie.api.definition.rule
The classes that make up a Rule definition.
org.kie.api.definition.type
Configuration API
Package Description
org.kie.api.conf
Runtime API
Package Description
org.kie.api.runtime
The runtime engine classes, including KieSession and StatelessKieSession.
org.kie.api.runtime.conf
org.kie.api.runtime.manager
org.kie.api.runtime.manager.audit
org.kie.api.runtime.process
The process runtime classes.
org.kie.api.runtime.query
org.kie.api.runtime.rule
The rule runtime classes.
Commands API
Package Description
org.kie.api.command
Event API
Package Description
org.kie.api.event
Comprehensive event API for all parts of the platform.
org.kie.api.event.kiebase
Events emitted while updating the definitions in the KieBase.
org.kie.api.event.process
Events emitted while process instances are executing.
org.kie.api.event.rule
Events emitted while rules are executing.
Time API
Package Description
org.kie.api.time
Classes related to calendars and time.
Task API
Package Description
org.kie.api.task
org.kie.api.task.model
CDI Support API
Package Description
org.kie.api.cdi
Other Packages
Package Description
org.kie.api.concurrent
org.kie.api.executor
org.kie.api.io
io library for working with Resources See ResourceFactory for more details
org.kie.api.logger
Logger classes used to log the KieRuntime's execution.
org.kie.api.management
org.kie.api.marshalling
Marshalling classes are used to marshall and unmarshal StatefulKieSessions See KieMarshallers for more detailed information.
org.kie.api.osgi
org.kie.api.persistence.jpa
org.kie.api.remote

KIE provides a knowledge-centric API, where rules and processes are first class citizens. The majority of KIE API is considered stable and should not change, experimental classes and APIs will be marked as such.

The most common interfaces you will use are:

  • org.kie.api.KieBase
  • org.kie.api.runtime.KieSession
  • org.kie.api.runtime.StatelessKieSession
  • org.kie.api.runtime.KieContainer
  • org.kie.api.builder.ReleaseId
  • org.kie.api.builder.KieScanner

Factory classes, with static methods, provide instances of the above interfaces. A pluggable provider approach is used to allow provider implementations to be wired up to the factories at runtime. The Factories you will most commonly use are:

  • org.kie.api.KieServices
  • org.kie.api.command.KieCommands
  • org.kie.api.io.KieResources

Typical example of loading and using knowledge resources (rules, processes, etc) found on classpath. By convention the KIE API expects file META-INF/kmodule.xml which is a marker file and also enables additional configuration. For very basic usage the file can just contain <kmodule xmlns="http://www.drools.org/xsd/kmodule"/>:

  KieServices kieServices = KieServices.Factory.get();
  KieContainer kieContainer = kieServices.getKieClasspathContainer();
  KieSession kieSession = kieContainer.newKieSession();
  kieSession.insert(new Fibonacci(10));
  kieSession.fireAllRules();
  kieSession.dispose();
